Description
The MWLNL-06 WNMG06 Internal Boring Bar is a left-hand internal turning (boring) bar for WNMG 06 inserts. It is used for boring, internal turning and internal facing on CNC and conventional lathes, with a 95° approach angle and lever (M-type) clamping for secure insert location.
Reading the code
MWLNL: M = lever/multi clamping, W = W-shape insert, L = 95° approach, N = insert clearance, L = left-hand.
Choosing a size
The size code gives the round shank diameter and length, e.g. S20R = Ø20 mm, 200 mm long. Use the largest, shortest bar that fits the bore: as a rule of thumb keep the overhang within about 3–4 × the shank diameter for steel bars to avoid chatter.
Specifications
| Brand | Zycron |
|---|---|
| Type | Boring bar (left-hand) |
| Insert | WNMG 06 |
| Approach angle | 95° |
| Clamping | lever (M-type) clamping |
| Bar sizes | S16Q (Ø16 mm shank, 180 mm long), S20R (Ø20 mm shank, 200 mm long), S25R (Ø25 mm shank, 200 mm long) |
