Description
The Helixor HX45 6mm 2 Flute Square Carbide End Mill is a 2-flute square-end solid carbide end mill designed for efficient slotting and material removal in steel and other ferrous materials. It is made from sub-micron tungsten carbide for rigidity and cutting stability, and the AlTiN coating improves heat resistance and wear protection.
Why choose this 2 flute carbide end mill?
With only two flutes, each flute has a larger chip gullet, so chips clear easily from full-width slots and deep pockets. That makes a 2-flute end mill the better choice for slotting and plunging, while a 4-flute tool is better suited to side milling and finishing.
Recommended materials
- Carbon and alloy steels
- Pre-hardened steels up to 45 HRC
- Cast iron
- Other ferrous materials
Typical applications
- Slotting
- Pocketing
- Plunge and ramp milling
- General material removal
Specifications
| Brand | Helixor |
|---|---|
| Type | Square end |
| Flutes | 2 |
| Material | Solid carbide (sub-micron tungsten carbide) |
| Coating | AlTiN |
| Cutting diameter (D1) | 6 mm |
| Cutting length (Ap1) | 15 mm |
| Overall length (L) | 50 mm |
| Shank diameter (D) | 6 mm |
| Suited to | Steels up to 45 HRC |
Buy Helixor 2 flute carbide end mills in South Africa
For CNC milling machines and machining centres. Hold it in a matching 6mm ER collet or a rigid BT tool holder to keep run-out low. Need cutting data? Use our free CNC feed & speed calculator, or WhatsApp our team on +27 83 570 6175. See the full Helixor HX45 2 Flute Carbide Endmills range and all Helixor solid carbide end mills. Stocked items are dispatched within 24 hours, with 1–3 working day delivery nationwide.
