The Nexcut TCT Beam Saw Scoring Blade – 180 x 4.3-5.3 / 3.2 x 30mm – 40T is a 180 mm TCT conical scoring blade for beam saws, with an adjustable 4.3–5.3 mm scoring width. It makes a shallow pre-cut in the underside of the board just ahead of the main blade, so laminated, melamine-faced and veneered panels come off the saw without chipped bottom edges.
Choosing the right scoring saw blade
On a panel or beam saw the main blade exits through the underside of the board, which is where chipping happens on coated panels. A scoring blade runs in the opposite direction and scores the bottom surface first, so the main blade leaves a clean, chip-free edge. For best results, match the scoring width to the main blade’s kerf.
Materials
- Melamine-faced chipboard and MDF
- Laminated and coated panels
- Veneered board
Specifications
| Brand | Nexcut |
|---|---|
| Blade type | Beam saw scoring blade |
| Diameter | 180 mm |
| Scoring width (kerf) | 4.3-5.3 mm |
| Plate thickness | 3.2 mm |
| Bore | 30 mm |
| Teeth | 40 |
| Tooth material | Tungsten carbide tipped (TCT) |
| Suitable machines | Beam saws with a scoring unit |
Before ordering, check that the diameter, bore and maximum RPM suit your saw.
Buy Nexcut saw blades in South Africa
For beam saws. Browse all Nexcut circular saw blades and scoring blades, or read our guide to panel saw and scoring blades. Need help matching a blade to your machine? WhatsApp us on +27 83 570 6175. Trade and reseller pricing available. Stocked items are dispatched within 24 hours, with 1–3 working day delivery nationwide.
